Condition: NEW
Manufacturer Part #: C8200-1N-4T

Cisco Catalyst 8200 Series Edge Platform - SD-WAN modular router for small and midsize branches that need higher throughput - 4x built-in Ethernet WAN Ports (2x Ethernet SFP and 2x RJ-45) - 8 core CPU with 8 GB DRAM memory default - Can be upgraded to 32 GB of DRAM - 1G SD-WAN throughput - Supports NIM and Pluggable Interface Module (PIM) slots - internal, fixed AC power supply - 1RU form factor

The Cisco Catalyst 8200 Series Edge Platforms with Cisco IOS XE SD-WAN software deliver Cisco's secure, cloud-scale SD-WAN and SD-Routing solutions to the small branch. The platforms are purpose-built for performance and integrated SD-WAN services along with flexibility to deliver security and networking services together from the cloud or on premises. They have a wide variety of interface options to choose from, with backward compatibility to existing WAN, LAN, and voice modules. Powered by Cisco IOS XE, a fully programmable software architecture, and API support, the Catalyst 8200 Series can facilitate automation at scale in both SD-WAN and SD-Routing deployments to achieve zero-touch IT capability while migrating workloads to the cloud. The platforms also come with a trustworthy solutions 2.0 infrastructure that secures them against threats and vulnerabilities through advanced integrity verification and remediation of threats.

Network Device Type: Router

Form Factor: 1RU

Routing Protocol: OSPF, BGP, RIP, ISIS

Processor / Type: Octa-Core

RAM / Total Installed Size: 8 GB

Flash Memory / Installed Size: 8 GB

Power / Device Type: Power Supply

Power Consumption Operational: 35 Watt

Power / Voltage Required: 90 to 264 VAC

Interfaces: 1 NIM slot and 4x 1 Gigabit Ethernet WAN ports: 2 SFP, 2 RJ45

Temperature Required: Operating temperature: 0 to 40C; Storage temperature: -40 to 70C

Humidity Required: Operating: 5% to 85%; Nonoperating and storage: 5% to 95%

Features: Multicore processors; Embedded IPsec VPN hardware acceleration; Integrated Gigabit Ethernet ports; Integrated security

Connectivity Technology: Wired

Data Transfer Rate: 1 Gbps

Data Link Protocol: Gigabit Ethernet

Encryption Algorithm: AES (256-bit); AES (128-bit); DES

Transport Protocol: Gigabit Ethernet

Authentication Method: RADIUS

Switching Protocol: Gigabit Ethernet

Remote Management Protocol: SNMP; SSH; DHCP

Width: 17.25 Inch

Depth: 11.8 Inch

Height: 1.73 Inch

Weight: 10 lb (4.54 kg)
