Product Overview
Condition: NEW
Manufacturer Part #: C9300-24S-M
Cisco Catalyst 9300-M Switch Managed via Cisco Meraki Dashboard - Layer 3, 24 port SFP switch (24 x 1G SFP ports; supports optional uplink network modules) - supports optional 10G or 40G modular uplink sold separately - has 2 FRU power supply module slots (ships with 1 default power supply); 715 watt default primary AC power supply is PWR-C1-715WAC-P - comes with 3 field-replaceable fans and support (N+1) redundancy - Supports the StackWise-480 stacking option - Enterprise and Advanced licenses are available in 1, 3, 5, 7, and 10 year terms
The Catalyst 9300-M switch is integrated under the Meraki dashboard to provide a simply powerful solution to the most demanding wired access applications. To satisfy high-bandwidth applications and the deployment of high-speed 802.11ax/wifi-6 access points, the Catalyst 9300-M provides multigigabit ports, 480G stacking, and modular 10/40G uplinks. They also deliver resiliency with fast stack convergence and StackPower, as well as provide Adaptive Policy using an over-the-wire tag which segments traffic into security groups to deliver scalable security.
By pooling and distributing power across C9300-Ms using a series of StackPower cables, the StackPower provides simple and resilient power distribution across the stack.
Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x Gigabit SFP
Performance: Switching capacity: 208 Gbps | Forwarding rate: 511.90 Mpps | Stacking bandwidth: 480 Gbps
Capacity: Priority queues: 8 | Maximum number of VLANs: 4094 | Active VLANs: 1000 | Link aggregation ports: 8
MAC Address Table Size: 32000 entries
Routing Protocol: VRRP, OSPFv2, static IP routing, STP
Remote Management Protocol: SNMP, DHCP, Syslog
Features: VLAN support, IGMP snooping, port mirroring, Broadcast Storm Control, firmware upgradable, DHCP snooping, ACL support, QoS, DHCP server, DAI, UDLD, DHCP relay, Port Security, Multicast filtering function, Cisco StackPower technology, 802.1x authentication, 3 fans, RBAC, push notification, Root Guard, Loop Guard, ZTP, MAB, BPDU Guard, VLAN trunking, CDP, Multicast routing, DSCP to CoS mapping
Compliant Standards: IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
Power: AC
Power Redundancy: Yes
Dimensions (WxDxH): 17.5 in x 17.7 in x 1.7 in
Weight: 16.84 lbs
