Product Overview
Condition: NEW
Manufacturer Part #: JG961A
HPE OfficeConnect 1950-48G-2SFP+-2XGT Switch - 48 x RJ-45 auto-negotiating 10/100/1000 ports, 2 x SFP+ fixed 1000/10000 SFP+ ports, 2 x RJ-45 1/10GBASE-T ports - Rack-mountable
The HPE 1950 Switch Series is a family of smart web-managed Gigabit switches with 10GbE uplinks for small business customers needing advanced high-performance connections. The series has 2 standard and 2 PoE+ models, 24- and 48-GbE ports, each with 2 10GBASE-T and 2 10G SFP+ high-bandwidth ports. True stacking of as many as 4 devices allows them to be logically administered as a single entity. The switches support Layer 3 static routing on IPv4 and IPv6. Other advanced features include ACLs, 802.1X, STP, RSTP, and MSTP.
Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 2 x Gigabit SFP / 10 Gigabit SFP+ + 2 x 10Gb Ethernet
Performance: Throughput (64-byte packet size): up to 95.2 Mpps / Routing/switching capacity: 128 Gbps
Capacity: Static routes: 32 / Virtual interfaces (VLANs): 8 / IPv4 routing table entries: 32 / IPv6 routing table entries: 32
MAC Address Table Size: 16384 entries
Jumbo Frame Support: 10KB
Routing Protocol: IGMP, VRRP, static IPv4 routing, static IPv6 routing, ECMP
Remote Management Protocol: SNMP 1, RMON 2, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Features: Auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), STP Root Guard, Link Aggregation Control Protocol (LACP), DHCP client, packet storm protection, Class of Service (CoS)
Compliant Standards: IEEE 802.3, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Power: AC 120/230 V (50/60 Hz)
Dimensions (WxDxH): 17.2 in x 6.3 in x 1.7 in
Weight: 6.61 lbs
