Condition: NEW
Manufacturer Part #: JL684B

HPE Instant On 1930 Switch - 24 x RJ-45 autosensing 10/100/1000 Class 4 PoE Ports and 4 x 1/10GbE SFP+ Uplink Ports - 370 W Class 4 PoE - Internal power supply - Supports mounting on the wall, on table top or under a table

The Aruba Instant On 1930 switches features advanced, smart-managed, fixed configuration Gigabit switches designed for small businesses that are easy-to-deploy and affordable. They're made to handle today's bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to enhance performance.

Using either the Instant On mobile app or the cloud-based web portal, you can quickly set up, monitor and manage the 1930 switch series from anywhere at any time. What's more, up to 30 W PoE power delivery is available out-of-the-box for your class 4 PoE devices, like access points, surveillance cameras and VoIP phones, all easily managed from the same platform.

Built-in security features protect your network from unauthorized access by allowing you to segment traffic and define access to each area of the network. And all of this is included in the price of the hardware--there are no hidden subscription or licensing fees.

Network Device Type: Switch

Form Factor: 1U

Connectivity Technology: Wired

Data Transfer Rate: 10 Gbps

Networking / Ports Qty: 28

Data Link Protocol: Gigabit Ethernet

Processor / Type: ARM Cortex A9

RAM / Total Installed Size: 512 MB

Flash Memory / Installed Size: 256 MB

Power / Device Type: Power Supply

Media Layer Supported: Layer 2, Layer 3

Power Consumption Operational: 30 Watt

Max Power Consumption: 490 Watt

Power / Voltage Required: 100 - 127 / 200 - 240 VAC

Power Over Ethernet (PoE) Support: Yes

PoE Power Consumption: 370 W Class 4

MAC Address Table Size: 16000

Jumbo Frame Support: 9216 bytes

Remote Management Protocol: SNMP

Routing Protocol: static routing

Authentication Method: RADIUS

10/100/1000BASE-T Ports: 24

SFP+ Ports: 4

Interfaces: 24 RJ-45 10/100/1000 ports, 4 SFP 1/10GbE ports

Width: 17.42 Inch

Depth: 10.42 Inch

Height: 1.73 Inch

Weight: 8.23 lbs.
