Product Overview
Condition: NEW
Manufacturer Part #: MS250-24P-HW
Cisco Meraki MS250 Stackable Switch - Managed via Cisco Meraki Dashboard - Total 28 ports - 24 x 1GbE RJ45 PoE Ports and 4 x 10 GbE SFP+ Uplinks - 370 watt PoE Budget - 2x Dedicated Stack Ports providing 80G of Stacking bandwidth - Fixed internal fan - Dual hot swap power supply (1 x MA-PWR-1025WAC PSU included) - Rack mountable
The Cisco Meraki MS250 series switches provide reliable access switching ideal for deploying in branches and small campuses. With stacking capabilities and 10G SFP+ uplinks on every model, redundancy and performance are guaranteed. This family also supports redundant, field-replaceable power supplies for mission-critical networks.
With 5 different models, capable of providing up to 740W of PoE+ power over a variety of port densities, including SFP+ capable uplinks, the MS250 line is fully ready to support branch and small campus infrastructure deployments.
Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE): PoE+
PoE Budget: 370 W
Performance: Switching capacity: 128 Gbps
Capacity: Forwarding table entries: 16000 | Tagged VLANs: 4095
Jumbo Frame Support: 9600 bytes
Routing Protocol: VRRP, OSPFv2, static IP routing
Remote Management Protocol: SNMP
Features: Flow control, DHCP support, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, E-mail alert, Broadcast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, DHCP server, SMS alert, IPv4 support, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), static routing, crossover detection, cloud managed, Bridge protocol data unit (BPDU), Role-Based Access Control (RBAC), Cisco Discovery Protocol, Root Guard
Compliant Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at
Power: AC 120/230 V (47 - 63 Hz)
Power Redundancy: Optional
Dimensions (WxDxH): 19.1 in x 16.4 in x 1.7 in
Weight: 10.58 lbs
