JH295A HP OfficeConnect 1950 12XGT 4SFP+ Switch (New)

Hewlett Packard

Write a Review
$1,995.00
SKU:
JH295A
UPC:
889296308591
Availability:
Inventory Available - But May Be Limited
JH295A HP OfficeConnect 1950 12XGT 4SFP+ Switch (New)
Adding to cart… The item has been added

Product Overview

Condition: NEW
Availability: Inventory Available - But May Be Limited

HPE OfficeConnect 1950 12XGT 4SFP+ Switch - 12 x RJ-45 1/10GBASE-T ports, 4 x SFP+ fixed 1000/10000 SFP+ ports (JH295A)

The HPE OfficeConnect 1950 Switch Series has an intuitive Web-based interface for simple customization of network operation. It supports true-stacking, the aggregation switch supporting up to two devices, while the access switches allowing up to four devices, to be logically administered as a single entity, simplifying administration while supporting greater network redundancy. Models support both rack mounting and desktop operation. These switches have IPv4 and IPv6 operation, with Layer 2 switching as well as Layer 3 static routing. Other features include: link aggregation to boost link performance; VLANs, Access Control Lists, and 802.1X network login for enhanced security; and three versions of Spanning Tree Protocol (STP) for added network resiliency.

General
Device Type Switch - 12 ports
Enclosure Type Desktop, rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 12 x 10GBase-T + 4 x 1 Gigabit / 10 Gigabit SFP+
Performance Routing/switching capacity: 320 Gbps ¦ Throughput (64-byte packet size): 238 Mpps ¦ Latency (100 Mbps): 5 µs ¦ Latency (1000Base-T): 5 µs
Capacity IPv4 routing table entries: 512 ¦ IPv6 routing table entries: 256
MAC Address Table Size 16384 entries
Jumbo Frame Support 10KB
Remote Management Protocol SNMP, RMON, HTTPS, CLI
Features Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, Quality of Service (QoS), 2MB packet buffer, DiffServ Code Point (DSCP) support
Compliant Standards IEEE 802.3, IEEE 802.3i, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
Processor 1 Cortex-A9: 1.25 GHz
RAM 1 GB SDRAM
Flash Memory 512 MB
Expansion / Connectivity
Interfaces 12 x 10GBase-T RJ-45 ¦ 4 x Gigabit / 10Gbit LAN SFP+ ¦ 1 x console RJ-45 ¦ 1 x management RJ-45
Power
Power Device Internal power supply
Power Provided 800 Watt
Voltage Required AC 120/230 V (50/60 Hz)
Power Consumption Operational 75 Watt
Miscellaneous
Cables Included 1 x power cable - 3.3 ft
Rack Mounting Kit Included
MTBF 81.8 years
Compliant Standards CISPR 22 Class A, EN55022, EN 61000-3-3, EN55024, UL 60950, CISPR 22, ICES-003 Class A, IEC 60950-1, EN 60950-1, ISO 7779, EN 61000-3-2:2006+A1:2009+A2:2009, VCCI Class A, EN 61000-3-2:2000, EN 62479:2010, GB 4943.1, EN 300 386 V1.6.1, EN 61000-3-3:2013, EN 55024:2010, EN 55022:2010 Class A, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 55032:2012
Software / System Requirements
Software Included HP Web browser, HP Intelligent Management Center
Dimensions and Weight
Width 17.3 in
Depth 6.3 in
Height 1.7 in
Weight 8.07 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 113 °F
Humidity Range Operating 10 - 90% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F
Humidity Range Storage 5 - 90% (non-condensing)
