Condition: NEW
Manufacturer Part #: JL807A

HPE Instant On 1960 Smart Managed Stackable Switch - 24 x RJ-45 autosensing 10/100/1000BASE-T ports (4 ports of IEEE 802.af/at/bt CL6 PoE and 20 ports of IEEE 802.af/at CL4 PoE) with 2 x 10GbE SFP+ and 2 x RJ-45 autosensing 100/1000/10GBASE-T Uplink Ports - 370 watt PoE Budget - Internal power supply - No extra licensing or subscription fees required - Supports mounting in standard 19 inch rack, on the wall, and table top or under table

Plug-and-play switches that work together with Instant On APs right out of the box.

The Aruba Instant On 1960 Smart-managed layer 2+ Ethernet switch series is an easy-to-use and affordable wired solution for networks supporting IT, mobile and cloud applications.

Aruba Instant On 1960 Switches are advanced, smart-managed, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to business grows, making adding more employees, devices and applications simple. Aruba Instant On 1960 switches are made to handle today's bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance.

True Stacking allows for redundancy while making it simple to configure, manage, and troubleshoot multiple switches as a single entity

Perfect for training centers, healthcare facilities and tech start-ups

Device Type: Switch - 24 ports - L3 Lite - managed - stackable

Enclosure Type: Rack-mountable 1U

Subtype: Gigabit Ethernet

Ports: 24 x 10/100/1000 and 2 x 10 Gigabit SFP+ and 2 x 100/1000/10GBase-T

Power Over Ethernet (PoE): PoE

PoE Budget: 370 W

Performance: Throughput: 95 Mpps | Switching capacity: 128 Gbps | Latency (100 Mbps): 4.4 µs | Latency (1 Gbps): 2.2 µs | Latency (10 Gbps): 1.1 µs

Capacity: MAC address entries: 16000 | IPv4 routes (static): 32 | IPv6 routes (static): 32

MAC Address Table Size: 16000 entries

Jumbo Frame Support: 9216 bytes

Routing Protocol: Static IP routing

Remote Management Protocol: SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUS

Features: Flow control, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Trusted Platform Module (TPM), Link Aggregation Control Protocol (LACP), Class of Service (CoS), Energy-Efficient Ethernet (EEE), BPDU Filter, auto voice VLAN, Media Endpoint Discovery (LLDP-MED)

Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1ab (LLDP)

Power: AC 100-240 V (50/60 Hz)

Dimensions (WxDxH): 17.4 in x 13.8 in x 1.7 in

Weight: 10.36 lbs
